Vam 21 Analog 6 5/8 with API 5CT casing DL-H -V-J-T manufacturer from China Dynoland International Trading Co.,Ltd

Price:	1.0~3000.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	Beijing, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: DL-H -V-J-T

Production Capacity: 5000MT/MONTH

Delivery Date: 50 days

Means of Transport: Ocean

Packing: Bundles as API packing requ...

premium connection: Tubing with Tenaris-Hydril ...

1. Size 4-1/2"-30"
2. API 5CT specification
3. Related Premium Connection
New vam/New vam Top/ Vam Top HC/Vam Top HT/Vam 21/Big Omega^^

1. Size 4-1/2"-30"
2. API 5CT specification

3. Related Premium Connection

New vam/New vam Top/ Vam TopHC/Vam Top HT/Vam 21/Big Omega^

4. Any questionsfeel free to contact Victor from Dynoland

Standard: API 5CT

Steel Grades: J55, K55, L80-1, N80, C90, C95,T95, P110.

Casing OD: 101.6-508mm, WT: 5.21-22.22mm
Tubing is used to for extracting petroleum and natural gas from a well. It isthe best substitution of EU tubing.

Can supplied with coupling, pup joint or connectionaccording to the specification of the tubing and casing

Casing Technical Specification(Standard API Spec 5CT)
Size	OD		ID		GRADE	WALL THICKNESS
	in	mm	in	mm		in	mm
4-1/2"	4.500	114.30	4.000	101.60	J55K55N80	0.250	6.35
4-1/2"	4.500	114.30	3.920	99.57	J55K55N80	0.290	7.37
5"	5.000	127.00	4.408	111.96	J55K55N80	0.296	7.52
			4.276	108.61	N80P110	0.362	9.29
			4.126	104.80	N80P110	0.437	11.10
5-1/2"	5.500	139.70	4.892	124.26	J55K55N80	0.304	7.72
			4.778	121.36	N80	0.361	9.17
			4.670	118.62	N80	0.415	10.54
7"	7.000	177.80	6.366	161.70	J55K55N80	0.317	8.05
			6.276	159.41	J55K55N80	0.362	9.19
			6.184	157.07	N80	0.408	10.36
9-5/8"	9.625	244.48	8.755	222.38	N80	0.435	11.05
9-5/8"	9.625	244.48	8.681	222.50	N80	0.472	11.99
10-3/4"	10.750	273.05	10.050	255.27	H40 J55K55N80	0.350	8.89
10-3/4"	10.750	273.05	9.850	250.19	J55K55N80	0.450	11.43
13-3/8"	13.375	339.72	12.615	320.42	J55K55	0.380	9.65tr
13-3/8"	13.375	339.72	12.415	315.34	J55K55N80	0.480	12.19
